Cooling Fan 614 NHR

Cooling Fan 614 NHR Specification

Size
60x60x15 mm

Blade Material
Plastic

Type
Cooling Fan

Installation Type
Panel Mount

Power
2.16W

Power Source
Electric

Voltage
12V DC

Energy Efficiency Rating
Standard

Speed Mode
Single Speed

Blade Diameter
60 mm

No. Of Blades
7

Color
Black

Material
Plastic Housing

Remote Operated
No

Connector Type
2-Wire

Weight
Approx. 70g

Noise Level
31 dBA

Service Life
50,000 hours at 25C

Model Number
614 NHR

Frame Material
Thermoplastic (UL 94V-0)

Bearing Type
Ball Bearing

Operating Temperature
-10C to 70C

Mounting Hole Spacing
Approx. 50 mm

Air Flow
23.9 CFM

Cooling Fan 614 NHR Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
1 Days

About Cooling Fan 614 NHR

The ebm-papst 614NHHR is a high-performance, compact $60 \times 25\text{ mm}$ DC axial fan engineered for demanding thermal management applications. Designed for maximum airflow and reliable cooling in dense electronic enclosures, power supplies, industrial automation equipment, and server hardware, this 24VDC fan delivers exceptional efficiency and durability.

Key Features & Benefits

High Airflow Performance: Delivers a powerful airflow of $31\text{ CFM}$ ( $54\text{ m}3\text{/h}$ ) at a high rotational speed of $6,850\text{ RPM}$ , making it ideal for high-heat dissipation needs.
Robust Construction: Built with a glass fiber-reinforced PBT plastic housing and PA impeller, ensuring high structural rigidity, thermal stability, and long operational life.
Precision Ball Bearing System: Features a dual-ball bearing design that supports mounting in any orientation and ensures extended service life under continuous operation.
Integrated Tachometer Output: Equipped with a 3-wire lead configuration that provides speed sensing (locked rotor/tachometer output) for real-time monitoring and system protection.
