COOLING FAN PMD2408PTB1-A

COOLING FAN PMD2408PTB1-A Specification

Blade Material
Plastic

Size
80 x 80 x 25 mm

Type
Cooling Fan

Installation Type
Panel Mount

Power
7.2W

Power Source
DC

Voltage
24V DC

Energy Efficiency Rating
Not Rated

Speed Mode
Variable

Blade Diameter
80 mm

No. Of Blades
7

Color
Black

Material
Plastic

Remote Operated
No

Bearing Type
Ball Bearing

Noise Level
44 dBA

RPM
Up to 4800 RPM

Operating Temperature Range
-10C to +70C

Current
0.30A

Airflow
Max 63.1 CFM

Connector Type
3-Pin

Model Number
PMD2408PTB1-A

COOLING FAN PMD2408PTB1-A Trade Information

Minimum Order Quantity
10 Pieces

Supply Ability
1 Piece Per Week

Delivery Time
1 Week

About COOLING FAN PMD2408PTB1-A

Sunon cooling fan

The Sunon PMD2408PTB1-A is an axial cooling fan designed for thermal management in industrial and electronic applications, such as inverters, servers, and telecommunication cabinets.

Outstanding Cooling Performance

Engineered to deliver up to 63.1 CFM airflow and rotation speeds up to 4800 RPM, the PMD2408PTB1-A ensures efficient heat dissipation even under challenging conditions. Its ball bearing design enhances durability and maintains reliable performance throughout extended operation.

Flexible and Easy Installation

With its standardized 80 x 80 x 25 mm panel mount size and a 3-pin connector, this cooling fan can be conveniently installed in a wide range of electronic devices and enclosures. The robust plastic construction withstands thermal stress and ensures long-term service life.

Versatile Operating Range

This fan operates efficiently between -10C to +70C, making it suitable for use in both low and high-temperature environments. Its variable speed mode allows precise control over cooling requirements, leading to optimized energy usage and noise management.

FAQ's of COOLING FAN PMD2408PTB1-A:

Q: How do I install the COOLING FAN PMD2408PTB1-A in my equipment?

A: Installation is straightforward: the cooling fan is designed for panel mounting using its 80 x 80 x 25 mm frame. Ensure the fan is securely fastened, and connect the 3-pin connector to your system's compatible header for power and speed control.

Q: What are the primary benefits of using the PMD2408PTB1-A cooling fan?

A: This fan provides effective cooling with high airflow (up to 63.1 CFM), reliable operation in a wide temperature range, and long-lasting ball bearing construction, reducing maintenance and helping extend the life of your equipment.

Q: Where can the PMD2408PTB1-A cooling fan be used?

A: It is suitable for a variety of electronics, including computers, servers, and industrial equipment, where efficient heat management is critical. Its wide operating temperature range and durable materials make it versatile for many environments.

Q: When is it necessary to use a variable speed cooling fan like this model?

A: Variable speed functionality is essential when you need cooling performance to adapt to changing system loads or ambient temperatures, helping balance cooling effectiveness with noise and energy consumption.

Q: What process should I follow to connect the 3-pin connector?

A: Align the 3-pin connector with your system's fan header and gently push it in place until it is secure. Ensure your system provides 24V DC power and is correctly configured for variable speed mode, if required.

Q: How does ball bearing construction benefit this cooling fan?

A: Ball bearings reduce friction, resulting in smoother operation, lower wear, and a longer service life, especially in applications with extended run times or fluctuating temperatures.
