Ebm-papst 3214 J/2n 24v Dc Cooling Fan

Ebm-papst 3214 J/2n 24v Dc Cooling Fan Specification

Blade Material
Plastic

Size
119 x 119 x 38 mm

Type
DC Cooling Fan

Installation Type
Panel Mount

Power
5.5 W

Power Source
Electric

Voltage
24 Volt (v)

Energy Efficiency Rating
Not Rated

Speed Mode
Single

Blade Diameter
119 mm

No. Of Blades
5

Color
Black

Material
Plastic and Metal

Remote Operated
No

Noise Level
48 dB(A)

Airflow
160 m3/h

Operating Temperature Range
-20C to +75C

Bearing Type
Ball Bearing

Model Number
3214 J/2n

Frame Material
Die-cast Aluminum

Connector
3-wire lead

Speed
3100 RPM

Ingress Protection
IP20

Ebm-papst 3214 J/2n 24v Dc Cooling Fan Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
2 Days

Ebm-papst 3214 J/2n 24v Dc Cooling Fan About

This high-performance ebm-papst 3214 J/2N axial fan operates on 24V DC with a 6.5W power rating. Designed for reliable thermal management in industrial electronics, it features a compact square frame and robust construction for demanding cooling applications.

Durable Design for Demanding Environments

Built with a die-cast aluminum frame and plastic blades, the 3214 J/2n cooling fan is ideal for panel mounting in environments that require stable performance. Its IP20 rating safeguards the internal components against accidental contact, making it suitable for many controlled and semi-protected settings.

Quiet Yet Powerful Cooling

Delivering up to 160 m3/h airflow at only 48 dB(A), the 3214 J/2n balances high performance with minimal noise output. This makes it particularly well-suited for sensitive electronics, industrial panels, and enclosed systems where excessive noise or heat could be an issue.

FAQ's of Ebm-papst 3214 J/2n 24v Dc Cooling Fan:

Q: How is the Ebm-papst 3214 J/2n 24V DC Cooling Fan installed?

A: The fan is designed for panel mounting, allowing secure attachment to electronic or industrial enclosures. It comes with a 3-wire lead connector for straightforward wiring during installation.

Q: What are the primary benefits of using a ball bearing fan like the 3214 J/2n?

A: Ball bearings enable the fan to operate reliably over a wide temperature range and extend its operational life, making it ideal for continuous-duty applications.

Q: When should this cooling fan be used in an application?

A: This fan is suitable for applications demanding efficient heat management, such as control cabinets, power supplies, server racks, and other enclosed electronic systems operating between -20C to +75C.

Q: Where can the 3214 J/2n fan be utilized most effectively?

A: It excels in panels, industrial machinery, automation equipment, and other environments requiring effective cooling and moderate ingress protection (IP20), but is best kept away from locations with direct water exposure.

Q: What is the process for connecting the 3-wire lead of this fan?

A: The 3-wire lead allows for simplified electrical integration with typical power and signal connections. Always ensure the voltage supply matches the fan's 24V DC requirement and observe correct polarity during connection.

Q: How does the single speed mode of the 3214 J/2n affect its operation?

A: With a single speed of 3100 RPM, the fan provides consistent cooling performance without the need for manual or automatic speed adjustment, resulting in reliable and predictable airflow.
