Fan 8314 HR

Fan 8314 HR Specification

Size
120mm x 120mm x 38mm

Blade Material
Plastic

Type
Air Cooling Fan

Installation Type
Panel Mount

Power
6 Watt (w)

Power Source
Electric

Voltage
24 Volt (v)

Speed Mode
Single Speed

Blade Diameter
119 x 119 mm (Approx. 120mm)

No. Of Blades
7

Color
Black

Material
Plastic Body with Metal Frame

Remote Operated
No

Connector Type
Standard 2-pin

Bearing Type
Ball Bearing

Current
0.13A

Insulation Class
Class B

Frequency
50/60Hz

Model No.
8314 HR

Fan 8314 HR Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
10 Pieces Per Day

Delivery Time
1 Week

Fan 8314 HR About

Size 80 X 80 X 32 24VDC

The ebm-papst 8314 HR is a high-speed, industrial-grade 24V DC axial cooling fan designed for high-performance heat dissipation in power electronics, control panels, and server enclosures. Featuring durable ball bearings, a glass-fiber reinforced PBT frame, and a PA plastic impeller, it delivers a high airflow capacity of up to $80text{ m}3/text{h}$ ($approx 47text{ CFM}$). Built-in electronic protection against reverse polarity and locked rotors ensures extended operational life and maintenance-free continuous service in demanding environments.

Optimal Airflow in a Compact Package

With a blade diameter of approximately 120mm and a seven-blade design, the Fan 8314 HR delivers superior airflow while maintaining a compact size. Its single-speed functionality is tailored for consistent cooling in settings where reliability matters most. This fan's balance between size and power offers efficient air movement without excessive noise.

Built to Last with Quality Materials

The Fan 8314 HR features a rugged plastic body combined with a metal frame for enhanced durability. Fitted with ball bearings and Class B insulation, it ensures a longer operational life and stable performance, reducing maintenance requirements for panel-mounted installations in demanding environments.

Flexible Installation and Easy Connectivity

Designed for hassle-free panel mounting, this model integrates seamlessly into new or existing setups. Its standard 2-pin connector simplifies the wiring process, allowing for straightforward electric integration, saving both time and technical resources during installation.

FAQ's of Fan 8314 HR:

Q: How do I install the Fan 8314 HR in a panel mount application?

A: To install the Fan 8314 HR, align the mounting holes with those on your panel, secure the fan using suitable screws, and connect the standard 2-pin connector to your 24V electric power supply. Ensure the airflow direction matches your system's cooling requirements before securing everything in place.

Q: What makes the Fan 8314 HR suitable for industrial or electronic applications?

A: Its robust build with a plastic body, metal frame, and ball bearing mechanism gives it the resilience required for continuous operation. The fan's Class B insulation, standard voltage, and reliable airflow make it ideal for cooling sensitive electronics and other panel-mounted industrial systems.

Q: When should I use this fan instead of other cooling solutions?

A: Choose the Fan 8314 HR when you need a dependable, medium-sized cooling solution for electrical panels or equipment. Its single-speed, 7-blade design ensures stable airflow in environments where consistent cooling is critical, making it suitable for both new installations and replacements in existing systems.

Q: Where can this fan be effectively utilized?

A: The Fan 8314 HR is best suited for use in industrial control panels, server racks, power supply enclosures, and electronic equipment where efficient cooling is essential. Its panel mount capability and standard sizing facilitate easy adaptation to various setups.

Q: What is the process for maintaining the Fan 8314 HR?

A: Routine maintenance involves keeping the fan clean from dust and debris, checking for secure mounting, and ensuring the 2-pin electrical connections remain tight. Ball bearings typically require minimal attention, contributing to the fan's longevity with basic care.

Q: How does using this fan benefit my equipment?

A: By providing consistent airflow and efficient heat dissipation, the Fan 8314 HR helps prevent overheating, extending the life of critical electronic components and maintaining system stability during continuous operations.
