Nidec D08A-24TS2 05 Cooling Fan

Nidec D08A-24TS2 05 Cooling Fan Specification

Blade Material
Plastic

Size
80mm x 80mm x 25mm

Type
Cooling Fan

Installation Type
Panel Mount

Power
2.40W

Power Source
DC Powered

Voltage
24 Volt (v)

Energy Efficiency Rating
Not Rated

Speed Mode
Single Speed

Blade Diameter
80 mm

No. Of Blades
7

Color
Black

Material
Plastic

Remote Operated
No

Model Number
D08A-24TS2 05

Frame Material
Plastic

Current
0.10A

Speed
Approximately 2900 RPM

Connector Type
2-Pin

Airflow
25.9 CFM (typical)

Bearing Type
Dual Ball Bearing

Operating Temperature Range
-10C to 70C

Noise Level
28 dBA (typical)

Nidec D08A-24TS2 05 Cooling Fan Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
2 Days

Nidec D08A-24TS2 05 Cooling Fan About

This 24V DC cooling fan features a 0.23A power rating and is designed for efficient thermal management in electronic systems. It offers reliable performance for industrial equipment, power supplies, and server cooling applications.

Efficient Airflow for Reliable Cooling

Engineered to provide a constant airflow of 25.9 CFM, the Nidec D08A-24TS2 05 cooling fan efficiently manages heat in confined spaces. Its seven-blade design, powered by a 24V DC source, ensures stable performance, protecting sensitive components from overheating.

Durable Dual Ball Bearing System

This model incorporates a dual ball bearing system that offers longevity and reliability, making it suitable for applications demanding consistent use. The bearings help minimize friction and wear, resulting in reduced maintenance and predictable operation over time.

Simple Installation and Versatile Usage

Manufactured with a lightweight plastic frame and blade, and sized at 80mm x 80mm x 25mm, the fan is easy to mount in panels. The straightforward 2-pin DC connector and single-speed operation make integration into existing systems hassle-free.

FAQ's of Nidec D08A-24TS2 05 Cooling Fan:

Q: How do I install the Nidec D08A-24TS2 05 cooling fan?

A: You can install the fan using the panel mount method by aligning the mounting holes on the fan with your panel or chassis and securing it with suitable screws. The 2-pin DC connector allows for quick and straightforward electrical connection to a 24V DC power source.

Q: What type of environments is this cooling fan suitable for?

A: The Nidec D08A-24TS2 05 is designed to operate reliably in environments with temperatures ranging from -10C to 70C, making it ideal for industrial, electronic, and general-purpose cooling applications.

Q: When should this fan be used in a system?

A: This cooling fan should be used whenever effective cooling and airflow are needed to prevent overheating in electronic enclosures, control panels, or any setup requiring stable temperature management.

Q: What are the main benefits of dual ball bearing construction?

A: Dual ball bearings extend the operational life of the fan, reduce noise levels, and require less maintenance compared to sleeve bearings, making the fan reliable for continuous and demanding usage.

Q: How much noise does the Nidec D08A-24TS2 05 produce during operation?

A: This cooling fan operates at a typical noise level of 28 dBA, which is considered quiet and suitable for environments where minimal acoustical disturbance is essential.

Q: Where can I use the Nidec D08A-24TS2 05 fan?

A: You can utilize this fan in various devices and equipment including industrial control boxes, server cabinets, 3D printers, or any electronics enclosure that fits its size and power requirements.

Q: What makes this cooling fan energy efficient?

A: While the Nidec D08A-24TS2 05 does not have a specific energy efficiency rating, its low power consumption of 2.40W at 24V helps limit energy usage compared to higher-powered fans.
